CPU
• Socket 754 for AMD ® Athlon™ 64 processor

Chipset
• NVIDIA nForce3 250
• Super I/O: ITE IT8712F chip
• Integrated peripherals:

1. Silicon Image sil3512 controller
2. GigaRAID ATA 133 RAID controller
3. Marvell 8001 Gigabit Ethernet controller
4. ICS1883 PHY 10/100 Ethernet controller
5. Realtek ALC850 Audio AC'97 Codec
6. TI TSB82AA2 IEEE1394b Controller (Firewire800)

Memory
• DDR400/333/266 184-pin DDR SDRAM DIMM modules
• Maximum capacity of 3GB via 3 DIMM Slots

Expansion Slots
• 1 x AGP slot (8x/4x-AGP 3.0 compliant), supports 1.5v display card only.
• 5 x PCI slots (PCI 2.3 compliant)
• 1 x DPS (Dual Power Systems) slot

Onboard IDE/SATA
• 2x NVIDIA ATA133/100/66 (4 drives) PLUS 4-drive IT8212 GigaRAID RAID 0, 1, 0+1)
• NVIDIA 2-Drive SATA (RAID 0, 1, JBOD)
• SiI3512 2-Drive SATA (RAID 0, 1, JBOD)

Onboard Audio
• 7.1 channel audio codec Realtek ALC850.
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement

Rear Panel I/O
• PS/2 Keyboard / Mouse
• 2 x USB 2.0/1.1 ports
• 2 x RJ45 ports
• 2 x COM ports
• 1 x LPT
• Audio (1 x Line-in / 1 x Line-out / 1 x Mic) connector

Internal I/O Connectors
• 4 x Serial ATA connector
• 4 x UDMA ATA 133/100/66 Bus Master IDE connectors
• 1 x FDD connector
• 2 x USB 2.0/1.1 connectors (supports 4 ports)
• 2 x IEEE 1394b connectors (supports 3 ports)
• S/P DIF input/output pin header
• 3 x cooling fan pin headers
• CD/AUX in
• 1 x Game/Midi connector

BIOS
• 2 x 4M bit flash ROM (DualBIOS), Award BIOS

Dimensions
• 30.5cm(L) x 24.5cm(W) - ATX Form Factor

Other Features
• Xpress™ Installation
• Xpress™ Recovery
• Q-Flash™
• @BIOS™
